品牌:崛鑫
起订:1台
供应:1000台
发货:3天内
此推杆包括普通丝杆和滚珠丝杆两种传动选择
DTW型主要技术参数及外形尺寸
|
型号 |
功率KW |
速度(mm/s) |
行程S(mm) |
L |
Lc |
B |
L1 |
L2 |
φA |
φF |
φE |
φ4 |
H |
I |
C |
E |
|||
|
I |
II |
min |
max |
min |
max |
||||||||||||||
|
DTW300 |
0.37 |
3.8 |
7.6 |
427+S |
427+2S |
245+S |
245+S |
245+2S |
20 |
100 |
121 |
42 |
25 |
12 |
140 |
210 |
25 |
20 |
450 |
|
DTW500 |
0.75 |
2.63 |
5.3 |
488+S |
488+2S |
276+S |
276+S |
276+2S |
20 |
100 |
121 |
44 |
35 |
14 |
150 |
210 |
25 |
20 |
500 |
|
DTW700 |
0.75 |
4.63 |
9.26 |
496+S |
496+2S |
283+S |
283+S |
283+2S |
25 |
100 |
121 |
52 |
35 |
14 |
170 |
210 |
25 |
20 |
540 |
|
DTW1000 |
1.1 |
4.67 |
9.34 |
496+S |
496+2S |
283+S |
283+S |
283+2S |
25 |
100 |
121 |
52 |
35 |
14 |
170 |
210 |
25 |
20 |
540 |
|
DTW1600 |
1.5 |
3.7 |
5.4 |
596+S |
596+2S |
263+S |
263+S |
263+2S |
35 |
125 |
176 |
64 |
35 |
25 |
220 |
288 |
30 |
35 |
607 |
|
DTW2500 |
2.2 |
2.4 |
4.8 |
736+S |
736+2S |
360+S |
360+S |
360+2S |
40 |
150 |
186 |
80 |
40 |
30 |
310 |
288 |
30 |
40 |
762 |
|
DTW4000 |
2.2-3 |
2.4 |
4.8 |
736+S |
736+2S |
360+S |
360+S |
360+2S |
40 |
150 |
186 |
80 |
40 |
40 |
310 |
310 |
40 |
40 |
762 |
|
DTW5000 |
2.2-3 |
2.4 |
4.8 |
736+S |
736+2S |
360+S |
360+S |
360+2S |
40 |
150 |
186 |
80 |
40 |
40 |
310 |
310 |
40 |
40 |
762 |
