品牌:伟控
起订:1片
供应:20片
发货:3天内
发送询价
| CPU | Intel®LGA1155 Socket Core i7/i5/i3/Pentium Processor |
| Chipset | Intel®Q67 Chipset |
| Memory | 4 *240 pin 4GB 1333/1066 Dual CH DDR3 SDRAM DIMM Max. up to 32GB |
| Expansion Slots | 1 *PCIex16,4*PCI,1*PCIex1,1*PCIex4 |
| 1 *MINI PCI-E&1 *mSATA socket | |
| Storage | 2 *Serial ATA3 6Gb/s & 3 *Serial ATA2 3Gb/s connectors support RAID0,1,5,10 |
| Audio | ALC662 6-Channel HD Audio CODEC |
| Ethernet LAN | Intel 82579LM&82583V PCI-E Gigabit Ethernet LAN |
| USB | Embedded 12 *USB 2.0/1.1 |
| Special Features | Support ACPI S3 |
| Support CPU Smart FAN | |
| Support Watch Dog | |
| Rear Panel I / O | 6 *USB 2.0/1.1 ports |
| 1 *PS2/KB Connector | |
| 2 *RJ-45 port | |
| 1 *HDMI port | |
| 1 *COM port | |
| 1 *VGA port | |
| 3 *Audio Phone Jack | |
| Internal I / O | 3 *USB 2.0/1.1 headers for 6 USB 2.0 ports |
| 1 *Parallel header | |
| 1 *GPIO header | |
| 9 *COM header(COM2 for RS232/422/485) | |
| 1 *TPM 1.2 header | |
| 1 *IR header | |
| 1 *Chassis Intrusion header | |
| 1 *AUDIO header | |
| 1 *24-pin & 8-pin 12V ATX Power connector | |
| BIOS | AMI EFI 64MB SMT Flash ROM |
| Form Factor | ATX form factor305mm x 244mm |
售后保障
本产品全国联保，享受三包服务，质保期为：二年质保
