品牌:APEXIS
型号:APM-H602-WS
起订:10台
供应:10000台
发货:7天内
新功能：
>支持Gmail/ Hotmail的功能
免费DDNS远程观看
>自由控制的ON / OFF的报警声
>自由ON / OFF控制报警记录
基本特征：
> H.264视频压缩格式
>支持双向音频功能
>支持音频输入和输出
>自由控制上传图片至FTP
>支持多达9个用户同时在线
>运动检测警报通过电子邮件的快照
>允许远程视图随时随地纪录
>多级密码保护的用户管理
> Wi-Fi的无线标准IEEE802.11符合
>支持WEP和WPA WPA2加密的无线
>支持手机用户界面，通过浏览器直接登录
>支持IE浏览器，Safari浏览器，火狐，谷歌Chrome浏览器或任何其他标准的浏览器
|
Specification: |
Model: APM-H602-WS-IR |
|
|
Image Sensor |
Image Sensor |
1/4" Color CMOS Sensor |
|
Display Resolution |
640 x 480 Pixels(300k Pixels) |
|
|
Lens |
f: 6 mm, F:2.0 (IR Lens)?? |
|
|
Mini.Illumination |
0.5Lux |
|
|
Lens |
Lens Type |
Glass Lens |
|
Viewing Angle |
60 Degree |
|
|
Audio |
Input |
1 channel audio input |
|
Output |
1 channel audio output |
|
|
Audio Compression |
G.711 |
|
|
Video |
Image Compression |
H.264, MJPEG |
|
Image |
30fps(VGA),30fps(QVGA) |
|
|
Resolution |
640 x 480(VGA), 320 x 240(QVGA) |
|
|
Flip Mirror Images |
Vertical / Horizontal |
|
|
Light Frequency |
50Hz, 60Hz or Outdoor |
|
|
Video Parameters |
Brightness, Saturation , Contrast ,Hue |
|
|
Communication |
Ethernet Interface |
Build in 10/100Mbps,Auto MDI/MDIX , RJ-45 |
|
Supported Protocol |
TCP/IP HTTP DNS DHCP PPPoE SMTP FTP SSL TFTP NTP ARP/RARP NFS RTSP RTP RTCP. |
|
|
Wireless Standard |
IEEE 802.11b/g/n |
|
|
Data Rate |
802.11b: 11Mbps (Max.), 802.11g: 54Mbps (Max.) |
|
|
Wireless Security |
WEP & WPA WPA2 Encryption |
|
|
Physical |
Infrared Light |
30 IR LEDs, Night visibility up to 35 meters |
|
Dimension |
175(L) x98(W) x98mm(H) |
|
|
Gross Weight |
App. 1400g |
|
|
Color Box |
250*145*125mm |
|
|
Net Weight |
App. 1200g ( accessories included) |
|
|
Power |
Power Supply |
DC 12V/2.0A (EU,US,AU adapter or other types optional) |
|
Power Consumption |
9 Watts (Max.) |
|
|
Environment |
Operate Temper. |
0° ~ 55°C? (14°F ~ 131°F) |
|
Operating? Humidity |
20% ~ 85% non-condensing |
|
|
Storage Temper. |
-10°C ~ 60° (14°F ~ 140°F) |
|
|
Storage Humidity |
0% ~ 90% non-condensing |
|
|
PC System Requirements |
CPU |
2.0GHZ or above (suggested 3.0GHz) |
|
Memory Size |
256MB or above (suggested 1.0GHz) |
|
|
Display Card |
64M or above |
|
|
Supported OS |
Microsoft Windows 2000/XP/Vista/7 |
|
|
Browser |
IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers |
|
|
Certification |
CE, FCC, RoHS |
|
|
Warranty |
Limited 1-year warranty |
|
Packing Details:
|
Model Number |
Carton Size |
Number / Carton |
Picture of Packing |
|
APM-H602-WS-IR |
270 x160 x 135 mm |
1pc / Carton |
|
|
310 x 270 x 135 mm |
2pcs / Carton |
||
|
310 x 270 x 255 mm |
4pcs / Carton |
||
|
755 x 270 x 135 mm |
5pcs / Carton |
||
|
755 x 270 x 255mm |
10pcs / Carton |
||
|
755 x 270 x 375 mm |
15pcs / Carton |
||
|
755 x 525 x 255 mm |
20pcs/ Carton |
